Unlike
other aerators, the patented Hines Drill & FillŪ can be used
to change the soil profile. The new, easier to load hoppers can be filled
with a wide variety of blends of soil amendments. Instead of a time and
labor intensive sweeping process, the Hines system drills and completely
fills the holes in one smooth operation. It increases the life of any
green and is the only known alternative to rebuilding greens with severe
problems. The Drill & FillŪ system also requires less top
dressing than conventional aerators.
Add
new life to old greens
Change
soil profile with variety of soil amendments
Gently
increase root depth
Fills
entire hole up to 8" deep
Uses
a 1" drill bit and fills .25 cu. yds. of material p/1,000 sq. ft.
Relieves
compaction for better air exchange and percolation
Leaves
greens immediately available for play

Tooling:
24 carbide tipped drill bits spaced
on 7.5" centers - 22.5" x 60" pattern
Drill Depth: Up to 8"
Drill Bit Sizes: Standard 1" dia. and 8" length. At 8"
deep with 1" drill bits will install .25 cubic yards of material per
1000 square feet
Aerification Speed: Up to 3500 sq. ft. per hour at 8" deep
Drill Bit Rotation: 300 at 3000 engine rpm
Hopper Capacity: .25 cubic yards per fill
As with the
Hines Drill Aerator, the Hines Drill & FillŪ relieves subsoil
compaction, improves drainage and air exchange, and still provides for
faster healing times than other types of aerators. Instead of removing
grass plugs, the Hines Drill & FillŪ gently folds back the
healthy grass surface during the aeration process. After a quick and easy
clean-up operation, the putting surface is left immediately playable.
Within days, the greens will have healed to the point of making the
aerification completely undetectable. The healing process will conclude
with increased root depth and a healthier turf surface.
The patented Hines Drill & FillŪ Aerator
has been re-engineered to be more efficient and easier to operate.
Previously marketed under the Floyd-McKay label, the
Hines system is simpler to operate, lighter, and faster than previous
backfill equipment. This revolutionary machine has the gentlest of
operating actions on your valuable turf. This innovative system is
transforming the turf maintenance industry by eliminating problems
associated with normal practices.
